Time Switch
Heavy-duty mechanical time switch is designed for industrial, commercial, and residential applications. Has the highest HP ratings in the industry for loads up to 40A resistive from 120-277 volts providing direct 24 hour time switch control of most loads. Provides 1 to 12 On/Off operations each day with minimum On/Off times of 1 hour. All models are equipped with 1 On and 1 Off tripper. Combination 1/2"-3/4" nominal knockouts, 1 on back and each side of case, 2 on bottom. Steel case is 7-3/4" H. x 5" W. x 3" D. Spring hasp with hole for lock, side hinged door closed. 3 mounting holes on back. UL listed. CSA approved.No. T104: Double pole/single throw switch, 208-277V, 60 Hz, HP rating: 5
No. T104R: Double pole/single throw switch, 208-277V, 60 Hz, HP rating: 5, Raintight, Available Only At Lexington, Woodburn, Mesquite |
