United Steel Product
|
Elevated Post Base
Allow installers to pre-align posts and preset post heights above concrete floors or footings. Eliminates post-to-concrete contact; moisture damage is reduced. Model No. EPB series is welded and primed, model No. EBG44 series is G90 galvanized for added corrosion resistance. Embed steel tube into wet concrete after screeding. A 3" minimum edge distance is required to achieve allowable loads. The tube shall extend above the concrete surface a maximum of 1". Not recommended for fence posts or unrestrained applications. Not designed to resist overturning (moment) loads. TZ indicates triple zinc.
| PostSize | Mfg. No. Dimensions |
|---|
| W | L | H1 | H2L |
|---|
| 4 x 4 | EBG44-TZ | 3-9/16 | 2-3/4 | 2-3/8 | 7-1/2 |
|---|
|
|
|
|
|
|
