United Steel Product
|
Top Mount Double I-Joist Hanger
Manufactured of G-90 galvanized steel. Double top mount hanger engineered for I-joist to header applications. Offers full lateral support of the I-joist top chord, eliminates the need for web stiffeners in most applications. Raised dimple nailing guides help assure correct 45 nailing into the I-joist bottom flange. The THO´s feature the patented Seat cleat that allows for quick, positive seating. The Seat cleat will hold the I-joist in place, eliminating spring back during nailing in the bottom flange.
| Number | Trus Joist Sizes | Gauge | Georgia Pacific Sizes | Boise Cascade Sizes | Louisiana Pacific Sizes | Roseburg Sizes | HangerWidth | HangerHeight | HangerDepth |
|---|
| THO15950-2 | (2) 9-1/2" TJI15 | 16 | (2) 9-1/2" GPI15 | | (2) 9-1/2" LPI26 | | 3-1/16" | 9-1/2" | 2-3/8" |
|---|
| THO15118-2 | (2) 11-7/8" TJI15 | 16 | (2) 11-7/8" GPI15 | | (2) 11-7/8" LPI26 | | 3-1/16" | 11-7/8" | 2-3/8" |
|---|
| THO17950-2 | (2) 9-1/2" TJI25 | 16 | (2) 9-1/2" GPI25 | (2) 9-1/2" BCI45 | (2) 9-1/2" LPI30 | (2) 9-1/2" RFPI20 or RFPI50 | 3-9/16" | 9-1/2" | 2-3/8" |
|---|
| THO20118-2 | (2) 11-7/8" TJI210 | 16 | | (2) 11-7/8" BCI5000 | | (2) 11-7/8" RFPI 400 | 4-3/16" | 11-7/8" | 3" |
|---|
| THO17118-2 | (2) 11-7/8" TJI25 | 16 | (2) 11-7/8" GPI25 | (2) 11-7/8" BCI45 | | (2) 11-7/8" RFPI20 or RFPI50 | 3-9/16" | 11-7/8" | 2-3/8" |
|---|
| THO35140 | (2) 14" TJI25 | 18 | (2) 14" GPI25 | (2) 14" BCI45 | (2) 14" LPI30 | | 3-9/16" | 14" | 2-3/8" |
|---|
|
|
|
|
|
|
