United Steel Product
|
Post Beam Cap
Designed to work with single, solid-sawn beams, but can be used with built-up beams. When installed to multiple beams made up of 2x lumber and shims, fasten the plys and shims together to act as a unit. 18-gauge, G90 galvanizing. C - 1-piece design; PB - 2-piece design; PBES and PBS - 2-piece design with extended side plates and wraparound post design. Easy retrofit installations. TZ indicates triple zinc. GC indicates gold coat.
| Post Size | Mfg. No. Dimensions |
|---|
| W1 | W2 | H1 | H2 | L1 | L2 |
|---|
| 4 x 4 | C44-TZ | 3-9/16 | 3-9/16 | 2-7/8 | 2-7/8 | 3-1/4 | 3-1/4 |
|---|
| 6 x 6 | C66-TZ | 5-1/2 | 5-1/2 | 2-7/8 | 2-7/8 | 5-1/4 | 5-1/4 |
|---|
| 4 x 4 6 | PB44-6TZ-TWO PB44-6GC | 1-1/2 | | 2-1/8 | 1-1/2 | 3-5/8 | |
|---|
| 6 x 6 6 | PB66-6TZ PB66-6GC | 1-1/2 | | 2-1/2 | 3 | 5-9/16 | |
|---|
| 4 x 4 | PBS44 | 1-7/16 | | 1-1/16 | 4-1/16 | 3-9/16 | 6-1/2 |
|---|
|
|
|
|
|
|
