United Steel Product
|
Wet Anchor
Formed, 1-piece design. Includes embossing for additional lateral strength. Insert into wet concrete after the pour. Embed the anchor so that the base plate is flush with the surface of the concrete. Finish: G90 galvanizing. A 2" minimum edge distance is required to achieve allowable loads. Not recommended for fence posts or other unrestrained applications. Not designed to resist overturning (moment) loads. Model No. WAS66 has a formed base providing a 1" stand off with high bearing capacity. Finish: Base and strap, steel 12-gauge. TZ indicates triple zinc.
| PostSize | Mfg. No. Dimensions |
|---|
| W1 | W2 | H1 | H2 | L |
|---|
| 4 x 4 | WE44-TZ | 3-1/2 | | 4-3/4 | 3-3/8 | 3-1/4 |
|---|
|
|
|
|
|
|
