2300 Series Door Closer
Economy closer for use on both exterior and interior doors in commercial and industrial applications. Available sizes are 3 or 4 and is bi-packed for regular arm (RA) or top jamb (TJ) installation. Closer is adaptable to parallel arm (PA) installation when parallel bracket model No. 289ASB is also selected. Closer is nonhold open, UL listed and nonhanded. Now with back check feature (BC): A valve controlled function that slows the door when it´s being opened, from 70 to the fully open position so that the door will not damage adjacent walls or hardware. Back check is included on closer. 5 year limited warranty.No. V2303BCX689: Satin aluminum finish (689), size: Interior up to 3´4" door, exterior up to 2´10" door
No. V2303BCX690: Dark statuary bronze (690), size: Interior up to 3´4" door, exterior up to 2´10" door
No. V2304BCX689: Satin aluminum finish (689), size: Interior up to 4´0" door, exterior up to 3´4" door
No. V2304BCX690: Dark statuary bronze (690), size: Interior up to 4´0" door, exterior up to 3´4" door |
