Aluminum Screen Frame
3/4" W. x 3/8" thick, .020 gauge. Screen retainer spline not included with aluminum screen frame, must order separately. Recommended screen spline size for use with aluminum screen .165 (11/64" diameter) and fiberglass screen .185 (3/16" diameter). For mitre cut window frame corners order model No. PL14282 or PL16029. For plastic square cut corners see sublist description for model No., must order separately. Available in 72", 94", and 12´2" lengths. Mill, white, and bronze finish.No. PL14053: 72" long, mill finish, uses plastic square cut corner model No. PL7721, PL14272, or PL16017
No. PL14056: 72" long, white finish, uses plastic square cut corner model No. PL7723, PL14274, or PL16019
No. PL14055: 72" long, bronze finish, uses plastic square cut corner model No. PL7722, PL14273, or PL16018
No. PL14059: 94" long, mill finish, uses plastic square cut corner model No. PL7721, PL14272, or PL16017
No. PL14062: 94" long, white finish, uses plastic square cut corner model No. PL7723, PL14274, or PL16019
No. PL14061: 94" long, bronze finish, uses plastic square cut corner model No. PL7722, PL14274, or PL16019
No. PL15624: 12´2" long mill finish, use plastic square cut corner model No. PL14272, PL7721, or PL16017
No. PL15627: 12´2" long white finish, use plastic square cut corner model No. PL14274, PL14274, or PL16019
No. PL15626: 12´2" long bronze finish, use plastic square cut corner model No. PL14273, PL14274, or PL16019 |
